  • Product Details
Detailed introduction:

全自动粉剂立式包装系统


Purpose:

The machine is mainly used for packaging powder products, such as milk powder, flour, starch, coffee powder, pepper, curry powder, protein powder, spices, Chinese medicine powder, chemical medicine and other industries.

Performance features:

1. The machine can automatically complete the following work: material lifting - screw metering - Coding - Bag - filling - sealing - counting - finished product output - finishing.

2. PLC servo and pneumatic control system, large touch screen constitute the core of drive control; high reliability and intelligence, and equipped with safety protection.

3. The touch screen can store the packaging process parameters of different products, and it can be used at any time when replacing products without resetting.

4. With a fault display system, the fault can be seen at a glance, so as to eliminate it in time.

5. Can be customized according to customer needs.

6. This machine has two choices: stainless steel model and carbon steel spray model.


Technical parameter:

型号/Model

YB-520F

YB-720F

包装速度/Packing speed

5-60 bags/min

5-55 bags/min

包装量/Packing volume

2000ml

4000ml

制袋尺寸/Making bag size

L: 80-400mm, W: 150-250mm

L: 80-450mm, W: 200-350mm

膜宽/Film width

≤ 520mm

≤ 720mm

卷膜厚度/Thickness of film roll

0.04-0.09mm

0.04-0.09mm

拉膜方式/Pulling film type

(双皮带拉膜) Double belt pull film

(双皮带拉膜) Double belt pull film

耗气量/Air consumption

0.8Mpa, 0.4m³/min

0.8Mpa, 0.4m³/min

包装精度/Packing accuracy

≤ ±1%

≤ ±1%

功率/Power

2.5 KW

3.0 KW

电源/Power supply

AC220V, 50/60Hz

AC220V, 50/60Hz

封口类型/Seal type

(背封袋,插角袋,盒式袋) Pillow seal, Gusset bag, Block bottom bag

(背封袋,插角袋,盒式袋) Pillow seal, Gusset bag, Block bottom bag

主机净重/Main machine net weight

550kg

700kg

主机尺寸/Main machine dimension

L1500 × W1140 × H1540mm

L1800 × W1250 × H1780mm
