Weibang is a professional filling machine and packaging machine manufacturer in China since 2005.
Axis: 2
Speed: up to 25 cases per minute (Depending on product and container characteristics. )
Payload: up to 20 kg
Applications: lunch packs, trays, bottles, pouches, and more
Container types: cases, trays, and totes
Whether you want to automate your end-of-line packaging, improve productivity, or reduce labor costs, Weibang Machiery is ready to respond with a case packer that suits your needs.
This packing machine adopts a self-developed high-speed flexible parallel robot for grasping movement, ensuring products remain secure during high-speed grabbing and transferring. It is widely used for automatic sorting, picking, transferring, and packing of soft pouches and boxed products such as fast-moving consumer foods and meat products;
Due to its extremely simple structural design, the machine is easy to maintain and repair, with minimal spare parts and low maintenance costs;
This packing machine occupies minimal floor space and can operate in confined areas, improving site utilization efficiency. The control system uses a handheld teach pendant (optional) + standard control buttons + signal switches, featuring automatic/manual control modes. Fault points can be located via the handheld teach pendant for effortless troubleshooting.
1. High speed, excellent precision, and strong usability.
2. Compact footprint, saving valuable floor space.
3. Adaptable to various materials via software-adjusted motions for packaging requirements.
4. Easily integrated into machinery equipment and production lines
5. Capable of material counting, stacking, and sorting.
6. Simplified robot structure reduces maintenance complexity and system costs.
7. Bearing-based mechanism replaces traditional springs, enhancing load capacity, repeatability, and reliability.
8. Lower cost compared to equivalent brands.
9. Intelligent multi-angle vision control.
10. Designed for food packaging—enhanced hygiene and safety.
WB-ZX1300-2 Technical Parameters Table
Performance Parameters | |
Product Model No. | WB-ZX1300-2 |
Number of Axes | 2 |
Arm Span (mm) | 1300 |
Max. Pick Height(mm) | 520 |
Rated Load（kg） | 20 |
Max. Payload（kg） | 25 |
Repeat Positioning Accuracy | XYZ（mm） ±0.2 |
Standard Cycle Rate（cycle/min.） /25-305-25mm | 25 |
Main body Weight（kg） | 80 |
Mounting Method | Suspended |
Supply Voltage（V） | AC220 |
Rated Power（KVA） | 4.5 |
I/O | 16 In / 8 Out (Expandable) |
Communication Protocols | TCP/IP, No-protocol, UDP, CANOPEN, MODBUS-TCP (Expandable) |
Vision Interface | Built in |
Ambient Temperature | 0~45℃ |
Relative Humidity | 15~85% |
Safety | Safety Stop, Emergency Stop |
Radiation | EMC/EMI Shielded |
Noise Level | ＜75dB |
Core Configuration | |
Controller | GUOYOU |
Servo Drive | GUOYOU |
Servo Motor | GUOYOU |
Reducer | BETTO |
