Weibang is a professional filling machine and packaging machine manufacturer in China since 2005.
YB-350X N95 mask machine compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Weibang summarizes the defects of past products, and continuously improves them. The specifications of YB-350X N95 mask machine can be customized according to your needs.
Machine list
Function introduction:
Personnel demand: 1 person (loading and receiving)
Raw materials for mask production: 3-5 layers of non-woven fabric, melt blown fabric / nose bar / ear belt line, etc.
Equipment appearance: stainless steel and industrial aluminum profiles.
Suitable industry: production of sanitary products, medical supplies, protective products and other industries.
The production line is controlled by the program to complete the automatic production, from 3 to 5 layers of raw materials, automatic completion of the operation, including the production process can be automatic nose beam, automatic breathing valve punching, folding forming and ear band welding; the equipment through servo feeding, positioning system with each production position to produce folding mask; in order to meet the market demand, according to the product can mold into Line adjustment, production of a variety of folding masks.
1.1 the machine is a fully automatic production folding mask equipment, from raw materials to finished products output, automatic completion.
1.2 the design concept is mature, which can meet the requirements of various folding masks.
1.3 high production efficiency, folding forming, ear band welding solid and beautiful, strong tension, automatic nose beam bar and automatic printing function.
1.4 the equipment has stable operation, long-time continuous action, and the product qualification rate is more than 98%.
1.5 automatic control of equipment, smooth operation and stable production.
Technical Parameter:
N95 automatic mask machine | parameter |
产能/capacity | 30-60pcs/min |
气压/air pressure | 0.6Mpa |
功率/Power | About 6.5kw |
电源/Power supply | 220V/50-60Hz |
产品尺寸误差/Accuracy | ±1mm(Without raw material error) |
净重/Net weight | 约2000Kg |
机器尺寸/weight | about 9500 (L)x 1300(W)x 1800(H)mm |
口罩类型/mask type | Folding masks, such as N95 masks for adults, N95 masks for children, 3M masks, etc |
Main configuration (some adjustments will be made according to market conditions)
Serial number | Machine configuration | brand |
1 | touch screen | Maintenance control / Siemens |
2 | PLC | vigor |
3 | Frequency converter | Delta |
4 | Stepper motor | Raysey |
5 | Electrical components | Chint / OMRON |
6 | Pneumatic components | Qi Li Ke / Yadeke |
 |  |
 |
|
