Mask machine
Weibang is a professional filling machine and packaging machine manufacturer in China since 2005.
Language
Weibang is a professional filling machine and packaging machine manufacturer in China since 2005.
Function introduction:
Personnel demand: 1 person (loading and receiving)
Raw materials for mask production: 3-5 layers of non-woven fabric, melt blown fabric / nose bar / ear belt line, etc.
Equipment appearance: stainless steel and industrial aluminum profiles.
Suitable industry: production of sanitary products, medical supplies, protective products and other industries.
The production line is controlled by the program to complete the automatic production, from 3 to 5 layers of raw materials, automatic completion of the operation, including the production process can be automatic nose beam, automatic breathing valve punching, folding forming and ear band welding; the equipment through servo feeding, positioning system with each production position to produce folding mask; in order to meet the market demand, according to the product can mold into Line adjustment, production of a variety of folding masks.
1.1 the machine is a fully automatic production folding mask equipment, from raw materials to finished products output, automatic completion.
1.2 the design concept is mature, which can meet the requirements of various folding masks.
1.3 high production efficiency, folding forming, ear band welding solid and beautiful, strong tension, automatic nose beam bar and automatic printing function.
1.4 the equipment has stable operation, long-time continuous action, and the product qualification rate is more than 98%.
1.5 automatic control of equipment, smooth operation and stable production.
Features:
Staff requirements: 1 person (loading, receiving)
Raw materials for mask production: 3 ~ 5 layers of non-woven fabrics, melt-blown fabrics / nose bridges / ear band lines and other raw materials.
Equipment appearance: stainless steel and industrial aluminum profiles.
Suitable for industries: production of sanitary supplies, medical supplies, protective supplies and other industries.
The production line is controlled by the program to complete automatic production, from 3 to 5 layers of raw materials, to complete the operation automatically, including the production process can have automatic upper bridge, automatic breathing valve punching, folding molding and ear strap welding; equipment through servo feeding, positioning The system cooperates with each production station to produce folding masks; in order to meet the market demand, the mold can be adjusted according to the product to produce a variety of folding masks.
1.1 This machine is fully automatic production of folding mask equipment, from raw materials to finished product output, completed automatically.
1.2 The design concept is mature and can produce various folding masks.
1.3 High production efficiency, folding forming, strong and beautiful welding of ear straps, strong pulling force, automatic upper bridge and automatic printing function.
1.4 The equipment runs steadily, has long-term continuous action, and the product pass rate is over 98%.
1.5 Automatic equipment control, smooth operation and stable product production.
技术参数/ Technical Parameter:
N95 全自动口罩机 /mask making machine | 参数/parameter |
产能/capacity | 30-60pcs/min |
气压/air pressure | 0.6Mpa |
功率/Power | 约6.5Kw |
电源/Power supply | 220V/50-60Hz |
产品尺寸误差/Accuracy | ±1mm(Without raw material error) |
净重/Net weight | about 2000Kg |
机器尺寸/weight | 约about 9500 (L)x 1300(W)x 1800(H)mm |
口罩类型/mask type | Folding masks, such as adult N95 masks, children N95 masks, 3M masks, etc. |
Main configuration (specifically adjusted according to market conditions)
序号/ Serial | 机器配置Machine configuration | 品牌BRAND |
1 | 触摸屏touch screen | 维控/西门子 Weikong / Siemens |
2 | PLC | 丰炜 Feng Wei |
3 | 变频器 converter | 台达 delta |
4 | 步进电机 step motor | 雷赛 leisai |
5 | 电气件 Electrical parts | 正泰/欧姆龙 Omron |
6 | 气动元件 Pneumatic Components | 气立可/亚德客 AirTAC |
